QNAP 22-BAY NAS 3.5"(0/16) 2.5"(0/6), XEON-E 8C-2.6GHz, 64GB, 10GbE, 2.5GbE, RPS, 3U, 5YR
$18,999.00
Tax included
QNAP TS-H2287XU-RP - NAS server - 22 bays - rack-mountable - SATA 6Gb/s - RAID 0, 1, 5, 6, 10, 50, JBOD, 60 - RAM 64 GB - 2.5 Gigabit Ethernet / 10 Gigabit Ethernet - iSCSI support - 3U
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
QNAP TS-H2287XU-RP - NAS server - 22 bays - rack-mountable - SATA 6Gb/s - RAID 0, 1, 5, 6, 10, 50, JBOD, 60 - RAM 64 GB - 2.5 Gigabit Ethernet / 10 Gigabit Ethernet - iSCSI support - 3U
Specifications
| RAM | 64 GB |
|---|---|
| Weight | 15.64 kg () |
| Processor | 1 x Intel Xeon E-2378 2.6 GHz (8-core) |
| Networking | 10 GigE, 2.5 GigE |
| Device Type | NAS server |
| Performance | Maximum volume size: 250 TB ? Maximum pool size: 308 TB ? Maximum number of storage pool: 128 ? Maximum shared folder size: 250 TB ? Maximum number of shared folder: 512 ? Maximum number of volume: 128 ? Maximum LUN size: 250 TB ? Maximum number of targets LUN: 256 ? Minimum snapshot interval: 5 min ? Maximum FTP connection: 1024 ? Local user account: 4096 ? Local group account: 512 ? Domain user/group account: 200000 ? System log & notification centre: 3000 events per second ? Virtual hosts: 32 |
| Localisation | Danish, Hungarian, Czech, Thai, Chinese (traditional), Chinese (simplified), Brazilian Portuguese, English, German, French, Italian, Norwegian, Portuguese, Polish, Finnish, Swedish, Russian, Spanish, Dutch, Greek, Turkish, Romanian, Japanese, Korean |
| Enclosure Type | Rack-mountable - 3U |
| Power Redundancy | Yes |
| Host Connectivity | 2.5 Gigabit Ethernet / 10 Gigabit Ethernet |
| Dimensions (WxDxH) | 48.3 cm x 63 cm x 13.3 cm |
| Storage Controller | RAID SATA 6Gb/s RAID 0, 1, 5, 6, 10, 50, JBOD, 60 |
| Product Description | QNAP TS-H2287XU-RP - NAS server |
| System Requirements | Microsoft Windows Server 2008 R2, IBM AIX 7, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Ubuntu 14.04, Red Hat Enterprise Linux 6.6, Apple OS X 10.10 Yosemite or later, Microsoft Windows Server 2016, CentOS 7.0, Microsoft Windows Server 2019, SuSE Linux 12 or later, Oracle Solaris 10 or later, Microsoft Windows 7 / 8 / 10 / 11 |
| Storage Operating System | QNAP QTS 5.0.1 |
| Installed Devices / Modules Qty | 0 (installed) / 22 (max) |
Dimensions & Weight (Shipping)
| Shipping Weight | 22.08 kg |
|---|
Environmental Parameters
| Min Operating Temperature | 0 C |
|---|---|
| Max Operating Temperature | 40 C |
| Humidity Range Operating | 5 - 95% RH (non-condensing) |
Expansion / Connectivity
| Expansion Bays | 16 (total) / 16 (free) x hot-swap - 3.5" 6 (total) / 6 (free) x hot-swap - 2.5" |
|---|---|
| Expansion Slots | 2 x PCI Express 4.0 x4 1 x PCI Express 4.0 x8 4 (total) / 0 (free) x DIMM 288-pin |
| Interfaces | 2 x Ethernet 10Gb 2 x 2.5 Gigabit Ethernet 4 x USB 3.2 Gen 2 - Type A |
General
| Device Type | NAS server |
|---|---|
| Host Connectivity | 2.5 Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable - 3U |
| Installed Devices / Modules Qty | 0 (installed) / 22 (max) |
| Width | 48.3 cm |
| Depth | 63 cm |
| Height | 13.3 cm |
| Weight | 15.64 kg () |
| Localisation | Danish, Hungarian, Czech, Thai, Chinese (traditional), Chinese (simplified), Brazilian Portuguese, English, German, French, Italian, Norwegian, Portuguese, Polish, Finnish, Swedish, Russian, Spanish, Dutch, Greek, Turkish, Romanian, Japanese, Korean |
Miscellaneous
| Cables Included | 1 x network cable 2 x power cable |
|---|---|
| Features | On/off switch, 4 LED indicators, reset button, dual boot, 80mm cooling fan, built-in 3 x 60 mm cooling fans |
| Included Accessories | 64 x flat head screws (for 3.5" HDD), 64 x flat head screws (for 2.5" HDD) |
Networking
| Data Link Protocol | 10 GigE, 2.5 GigE |
|---|---|
| Network / Transport Protocol | PPTP, L2TP, IPSec, FTP, DDNS, SFTP, IPv4, IPv6, WireGuard, TFTP, QBelt, OpenVPN |
| Remote Management Protocol | SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, TFTP, SSH, RADIUS |
| Network Services Compatibility | Microsoft CIFS, FTPS, Server Message Block (SMB), Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), Network File System v3 (NFS v3), Network File System v4 (NFS v4) |
| Performance | Maximum volume size: 250 TB Maximum pool size: 308 TB Maximum number of storage pool: 128 Maximum shared folder size: 250 TB Maximum number of shared folder: 512 Maximum number of volume: 128 Maximum LUN size: 250 TB Maximum number of targets LUN: 256 Minimum snapshot interval: 5 min Maximum FTP connection: 1024 Local user account: 4096 Local group account: 512 Domain user/group account: 200000 System log & notification centre: 3000 events per second Virtual hosts: 32 |
| Features | Firewall protection, VLAN support, antivirus analysis, DHCP server, Domain Controller, port trunking, EXT4 file system, SSD trim, Windows ODX, FXP support, hybrid backup sync, Qfiling, Qsirch, SQL Server, VJBOD Cloud, Qsync, QuMagie, Smart Fan, QmailAgent, QuWAN, user quota managerment, LDAP server, Storage Pool, SED Storage Pool, JBOD Expansion, Disk, Enclosure Locate, Disk S.M.A.R.T. Scan, Disk S.M.A.R.T. Data Migration, Disk Roaming, Disk Standby, Volume Snapshot, Snapshot Retention Policy, Self-serve Snapshot Recovery, Application Consisted Snapshot, Snapshot Full Clone, Snapshot Replica / Vault, SSD read-only Cache, SSD read-write cache, SSD write-only cache, SSD profiling tool, External Device Management, Mount Smart Phone (MTP), shared folder permission, advanced folder permission, group quota, folder quota, home folder, Resource Monitor, Virtual Switch, Allow/Deny List, Access Protection, Service binding, DA Driver Analyzer, floating point unit, SSD cache acceleration support, fibre channel service, file-based iSCSI LUN, block-based iSCSI LUN, LUN snapshot, auto tiering, RAID Group, RAID Level Migration, RAID Expansion, Storage Pool Expansion, RAID Hot Spare, RAID Sync/Rebuild/Scrubbing, SSD life estimation, domain security, security counselor, malware remover, 2-step verification, HybridMount, Hyper Data Protector, Boxafe, Windows ACL, schedule on/off, iSCSI service, SSD Cache RAID, media streaming add-on, GPU pass-through, Secure Erase, QVPN Service, External RAID Device Management |
| Encryption Algorithm | SSL, TLS, TLS 1.0, FIPS 140-2, 256-bit AES, TLS 1.1, TLS 1.2, AES-NI, TLS 1.3 |
Power
| Power Device | Internal power supply |
|---|---|
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Power Provided | 550 Watt |
Processor / Memory
| Processors Installed | 1 x Intel Xeon E-2378 2.6 GHz |
|---|---|
| Number of Cores | 8-core |
| Max Supported Qty | 1 |
| Max Turbo Speed | 4.8 GHz |
| RAM | 64 GB (installed) / 128 GB (supported) - DDR4 |
| Features | ECC |
| Flash Memory Installed | 5 GB |
Software / System Requirements
| Storage Operating System | QNAP QTS 5.0.1 |
|---|---|
| Software Included | McAfee, IronWolf Health Management |
| OS Required | Microsoft Windows Server 2008 R2, IBM AIX 7, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Ubuntu 14.04, Red Hat Enterprise Linux 6.6, Apple OS X 10.10 Yosemite or later, Microsoft Windows Server 2016, CentOS 7.0, Microsoft Windows Server 2019, SuSE Linux 12 or later, Oracle Solaris 10 or later, Microsoft Windows 7 / 8 / 10 / 11 |
Storage Controller
| Type | RAID |
|---|---|
| Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 60 |
Product information source: Dicker Data Partner Portal.
